12W 2G11 SMD Tube to Replace Philips Master Pl-L 36W

  • Category:2G11 LED Tube
  • Views:3637
  • 2g11 led tube
  • 2g11 4 pins
  • Dimension: 320 × 36mm
  • 60PCS 2835SMD LED
  • Product Manual:12W 2G11 SMD Tube to Replace Philips Master Pl-L 36W
BASIC INFO

12W 2G11 SMD Tube to Replace Philips Master Pl-L 36W

Equal to PHILIPS MASTER PL-L 36W/830/4P/ OSRAM DULUX L 36W/827


Model No. OED-G36320-12W
Power Consumption: 12W
LED Type: 60PCS 2835SMD LED
Luminous Flux: 1200LM
Lamp Base: 2G11
Input Voltage: AC100-240V/50-60Hz

Color Temperaturewarm white: 2700~3500K /pure white: 4000~4500K /cool white: 6000~7000K
Color Rendering Index: ≥ 75Ra;
Housing Material: Aluminum+PC cover;
Dimension: 320 × 36mm;
Operating Temperature: -20° C ~ +45° C;
Body Temperature Less than 55° C at room temperature 25° C;
Storage Temperature: -40° C ~ +80° C;
Humidity: 0~90%;
Lifespan ≥ 50, 000hrs

Product Features:
1.Works as replacement for PHILIPS MASTER PL-L 18W/827/4P or OSRAM DULUX L 18W/840.
2.With features of high efficiency, energy-saving and long lifespan etc, 2G11 plug-in tube adopts branding LED as light source.
3. Integrated constant current LED driver generate much less heat and lengthen lifespan from 30, 000hrs to 50, 000hrs.
4. Frosted PC cover, transparent PC cover are optional.


Applications:
Underground garage, parking lot, household, shool, hospital, office, workshop, supermarket etc;
Note:
Must remove the starter and magnetic ballast from the conventional fluorescent fixtures, no need to rewire.
