Indoor Factory and Outdoor Stadium Lighting 5 Years Warranty 1500W LED High Bay Flood Lamp

  • Product Item:OED-HM1500W
  • Category:Module LED Floodlight
  • Views:199
  • Stadium Flood Light
  • 1500W LED Stadium Light
  • 1500W LED High Mast Light
  • Flood Light 1500W
  • Product Manual:Indoor Factory and Outdoor Stadium Lighting 5 Years Warranty 1500W LED High Bay Flood Lamp
BASIC INFO
Technical Data


Item name
1500W indoor and outdoor LED high bay flood lamp
Power
1500W
Light Source
Filips Chip 3030 SMD LED--840PCS
Input Voltage
AC85-277V / 50-60Hz
Color Temperature
3000-6500K
Light effect
125LM/W
Lumen
187,500LM
PF
≥0.95
CRI
Ra.≥80
IP
66
Viewing angle
10°   25°   45°   60°   90°
Materials
1070 Aluminum and PC lens
Operating Temp.
-25ºC to +50ºC
Applications
Outdoor lighting, Airport lighting, Football Field, Parking lot,pubilic works,
port, square, depot, highway etc.

Qty / CTN
1PC
N.W.
37KG
G.W.
40KG
Lamp dimensions
L.890 x W.536 x H.160mm
Carton size
97 x 62 x 24cm
Lifetime
50,000 hours
Quality warranty
5 years
Certificates
CE,ROHS, EMC, SAA,CB,ETC,LVD, ISO9001
Product manual

1. This High Mast LED Light adopts imported 3030 chip, energy saving and environmental protection, high luminous brightness and long service life;

2. It adopts 1070 aluminum material shell, the surface is subjected to special oxidation treatment and heat conduction treatment, which can improve the heat generated by the lamp board and the power source of the lamp to quickly lead out the lamp body, reduce the temperature difference, reduce the junction temperature of the light source and ensure the light source light decay 3%, life expectancy of 50,000 hours;

3. Adopt constant current power supply, high efficiency, low heat, high constant current precision; unique structure, high efficiency, energy saving and green environmental protection.

Product features

*High quality SOSEN or MEANWELL driver.


*Original Filips 3030SMD, 125LM/W.


*High heat conducting 1070 aluminum lamp housing, excellet structure for heat dissipation.

*Surface of the lamp is anti-corrosion treated and powder coating, can be used at seaside.

*Dust-proof, moisture proof and waterproof, IP66.

*Excellent optics design, higher luminous efficiency.

*Energy saving 60-70% comparing with traditional lamps.

*5 years warranty

Product details


 1. Please read the instruction manual of High mast LED light before use.
 2. Non-specialist electricians please do not repair or modify this product without authorization.
 3. Please turn off the power before installation.
 4. Before installation, please check whether the voltage marked on the high pole light is consistent with the input voltage to be connected.
 5. In order to ensure the service life of the product, please do not use it in a place with strong acid mist.
 6. Pay attention to shock protection during installation and transportation.
 7. Before installation, be sure the installation position can withstand 10 times the weight of the product, and install it in a flat place without vibration, no swing, no fire hazard;
 8. If the lamp fails, please place the lamp in one place and send it back to the company for inspection and repair.
 9. If the lamp body or cable is damaged, please stop using it immediately.

Applications


   Suitable for squares, airports, football fields, tower cranes, shipyards, mines, workshops, factories, warehouses, highway toll stations, highways, tunnels, crossroads, highway rest service areas, gas stations, large supermarkets, exhibition halls, Outdoor gymnasiums, piers and other places where lighting is required.



About us

We have 6 production lines at production department, including assembling, inspection and aging test lines.
Production ability: 5-7 days for 100pcs LED high bay light, and 10-15 working days for 500pcs LED high bay light at common requirements.

Each Lamp must pass 24 hours aging test and high voltage (2KV, 4KV, 6KV) surge test before we make packing and make delivery.

Our Services:
1. For all your inquires about us or our products, we will reply you in detail within 24 hours;
2. Excellent design team with designers of more than 12 years experience, can offer professional advice for practical application;
3. 5000,000 pcs light source annual production capacity, the products export to EU market, American market, Russia, Kazakhstan, Australia, South Africa, Zimbabwe, Vietnam, etc;
4. Good OEM & ODM business ability, 6 production lines meet your shipping requirement;
5. Export port Shenzhen, Hongkong or Shanghai;
6. Discount available for bulk order;
7. High quality component and material, Filips, Bridgelux, 3030SMD, 5050SMD, Epistar LED chips, MW / Sosen / HT/ TUV SAA CE listed driver etc, depend on your needs.

Payment Terms:
TT Bank Transfer, support 30% deposit and 70% before delivery;
PayPal, western union, Alipay etc.
NO O/A.

Delivery time:
Samples and less than 100pcs in 5-7 working days;
300pcs in 7-8 working days;
500pcs in 15 working days.

About Shipping:
Samples sent by DHL, TNT, FedEX, UPS, SF Express, Aramex etc. Door to door, you may pay customs tax depends on your customs policy.
By air or by sea for bulky orders available.

FAQ:

1. Are you factory supplier?
Yes, we are manufacturer of LED lamps since 2008 and we have our own factory, supply duable super quality items and reliable after-sale service.

2. Do you supply OEM or ODM?
Yes, we can supply OEM and ODM serice with favorable price and we have our own mould workshop, your brand and logo can be printed on the items.

3. How long will it spend for our orders to be sent out?
It takes 5-7 days for samples at common requirements, and 10-15 days for big order such as 500pcs led high bay flood light.

4. What about your after-sales servie and warranty policy?
We offer 5 years warranty for this led high bay flood light, by supplying you the lamp parts or new replacements for free during the warranty period for any non-human defective lamps.
