Ac85-265v inbuilt driver 60cm 2ft Aluminum and pc lighting led t5 fluorescent lamp

  • Product Item:OED-F16600-9W
  • Category:T5 LED Tube
  • Views:176
  • Single T5 Tube Light
  • Lumens: 100LM/W
  • CRI> 80Ra
  • Warranty: 3 years
  • Product Manual:Ac85-265v inbuilt driver 60cm 2ft Aluminum and pc lighting led t5 fluorescent lamp
BASIC INFO

Ac85-265v inbuilt driver 60cm 2ft Aluminum and pc lighting led t5 fluorescent lamp


T5 9W 2 FT led tube light

T5 tube without fixture with ac85-265v

CE LVD EMC ROHS Approval

3 Years Warranty

Main Technical Data:

Item Name T5 led tube light 3FT 9W
Power consumtion 9W
Light Source 2835SMD, Epistar
Lamp dimensions T5 - 600mm / Standard size: L.562 * D.17mm
Color temperature 2700-3000K, 4000-4500K, 6000-6500K
CRI Ra.>80
Power Factor 0.90
Input voltage AC85-265V / 50-60Hz
Main Materials Aluminum & PC
Lumens 900- 1000LM
Lifetime 35,000hours
Quality warranty 3 years
Applications Garage, corridor, staircase, office, classroom, hospital etc
Inner box Neutral color box each lamp
Item N.W. 90gram
Qty / carton 100pcs
CTN Size / G.W 65 x 23 x 23cm / 10.5KG
Certificates CE, LVD, EMC, RoHS



Model
F1660-09W
F1690-13W
F16120-18W
F16150-24W
Overall length
562MM
862MM
1162MM
1462MM
Input volt
AC85-265V
AC85-265V
AC85-265V
AC85-265V
Watt
9W
13W
18W
24W
LED Type
Epistar SMD
Epistar SMD
Epistar SMD
Epistar SMD
CCT
3000K - 6500K
3000K - 6500K
3000K - 6500K
3000K - 6500K
Lumens
900LM
1300LM
1800LM
2400LM
CRI
>80Ra.
>80Ra.
>80Ra.
>80Ra.
Power Factor
>0.90
>0.90
>0.90
>0.90
Operating Temp
-30~+55℃
-30~+55℃
-30~+55℃
-30~+55℃
Warranty
3 years
3 years
3 years
3 years

CCT (3000K, NW 4000K, CW 6000K):

warm white cool white.jpg


Application:

T5 led tube light is widely used for office, classroom, workshop, underpass, garage, hospital, household and other indoor public lighting, etc.


Installation:


Installation instructions:
1. Non-professional technicians, please do not repair or modify this product without authorization;
2. Please turn off the power before installation to avoid improper operation. ;
3. Before installation, please check whether the voltage marked on the lamp is consistent with the input voltage to be connected;
4. In order to ensure the service life of the product, please do not use it in a place with strong acid mist;
5. Pay attention to earthquake prevention during installation and transportation;
6. Before installation, ensure that the installation position can withstand 10 times the weight of the product, and install it in a flat place without vibration, no swing, no fire hazard;
7. If the lamp fails, please place the lamp in one place and send it back to the company for inspection and repair.
8. If the lamp body or cable damaged, please stop using it immediately.


Aging test :
Each Lamp must pass 24 hours aging test and high voltage (2KV, 4KV, 6KV) surge test before we make packing and make delivery.


Certificates:

The LED T5 Tube Light with CE, RoHS, EMC, LVD approval.

CE EMC Sensor Tube.jpg


Our Services:
1. For all your inquires about us or our products, we will reply you in detail within 24 hours;
2. Excellent design team with designers of more than 10years experience, can offer professional advice for practical application;
3.  5,000,000 pcs light source annual production capacity, the products export to Europe, South America, Russia, etc;
4. Good OEM & ODM business ability, 8 production lines meet your shipping requirement;
5. Export port, Shenzhen;
6. Discount offered is based on order qty;
7. High quality component and material, Epistar LED chips and IC Constant current inbuilt driver.


Payment Terms:
TT Bank Transfer, support 30% deposit and 70% before delivery;
PayPal, western union, Alipay etc.
NO O/A.


Delivery time:
Samples and less than 100pcs in 3-5 working days;
500pcs in 7-8 working days;
3000pcs in 15 working days.


About Shipping:
Samples sent by DHL, TNT, Fed EX, UPS, SF Express, Aramex etc. Door to door, you may pay customs tax depends on your customs policy.
By air or by sea for bulky orders available.

shipping about.jpg

FAQ:
1. Are you factory supplier?
Yes, we are manufacturer of T5 led tube light since 2008 and we have our own factory, supply duable super quality items and reliable after-sale service.


2. Do you supply OEM or ODM?
Yes, we can supply OEM and ODM serice with favorable price and we have our own mould workshop, your brand and logo can be printed on the items.


3. How long will it spend for our orders to be sent out?
It takes 5-7 days for samples at common requirements, and 12-15 days for big order such as 3000pcs T5 led tube lights.


4. What about your after-sales servie and warranty policy?
We offer 3 years warranty for this T5 led tube light, by supplying you the lamp parts or new replacements for free during the warranty period for any non-human defective lamps.
